Creality 3D Scanner CR-Scan Ferret, 3D Scanner for 3D Printing and Modelling, Portable Scanner with Fast Scan 30fps, 0.1mm Accuracy, Scan Mode with Two Fiche Technique et Prix au Maroc

How to use:
1. Make sure the scanned object is larger than 50 x 50 x 50 mm. After connecting the device, select the option that corresponds to your project.


2. If the displayed distance is “perfect” and the items are tracked, you can start scanning.


3. When scanning, return to the previous scanned area when removing and hold it for a few seconds to restore tracking. Try enabling the “exclusion issue” of the lower left corner or lower right corner (window) or lower right corner.


4. For small objects, it is recommended to use tools such as turntables to scan at least three times around the object at 360°.


Reminder: Please check if OTG function is enabled when connecting.


If you are a beginner, scan patiently. I think you will find your skills and succeed.


Recommended scan object.
Ideal for scans of medium and large objects. Recommended: face, human body, sculpture, sculpture, etc.


Not suitable for transparent, reflective pores, and very fine objects. Non-static objects, e.g. Move the animals.


Large objects such as walls and rooms and keys, coin scissors, gears, jewelry or microelectronic components such as super small items.


Product Name: CR Sweeping Board
Accuracy: 0.1mm
Resolution/Spot Spacing: 0.15mm
Single shooting area: 560 x 820 mm x 700 mm
Working distance: 150~700mm
Minimum scanning: 50 x 50 x 50 mm
Image speed: 30 fps
Light source: infrared
Outdoor Scanner: Support under strong light scanning.
Tracking mode: visual tracking
Color structure: stand
Output:
Package Dimensions ‏ : ‎ 24.5 x 19 x 9 cm; 1.2 kg
Date First Available ‏ : ‎ 19 July 2023
Manufacturer ‏ : ‎ Creality
ASIN ‏ : ‎ B0CC9D2NBX
Manufacturer reference ‏ : ‎ EVECR Ferret
Country of origin ‏ : ‎ China
Spare part availability duration ‏ : ‎ Spare part information not available or provided

Firmware Upgrade: Now you can upgrade the Creality Ferret scanner by updating the latest firmware directly from our official website. This all-new version has been subjected to algorithmic optimizations, resulting in smoother scans and better scanning quality. It also allows you to scan even smaller objects and thus expands the possibilities you can get with our state-of-the-art scanner.
Dual Mode Scanning & High Precision Scanning CR-Scan Ferret offers two high-range and high-precision modes, which can be selected according to needs, for example B. human body, furniture, car, medium-sized statue. Wide range mode allows a single detection area of up to 560 x 820 mm. High precision mode with accuracy up to 0.1mm and 0.15mm 3D resolution ensures better dimensional accuracy and capture more details.
High scan speed: Unlike other scanners, the scan rate of the updated version of CR-Scan Ferret is up to 30 FPT, which improves scanning fluid. For optimal scanning results, highly configured devices are needed whose computing power affects the actual rate.
Color scanning: Built-in high-resolution color camera that really reflects the real world. In addition, it is equipped with advanced optical technology to work well even in direct sunlight.
Compact design: portable scanner that can be easily held with one hand, weighs only 105g and fits easily in your pocket or backpack. The Ferret scanner has a low power consumption and can therefore be powered by a 5V external battery and even via your Android phone.
