Fiche Technique ISEEVY H.264 Video Decoder with HDMI VGA SDI Output support 59.94 and 29.97 SDI output for Advertisement Display, IP Encoder Decoding, Network Stream Decoding support SRT RTMP RTSP UDP HTTP au Maroc
ISEEVY H.264 SDI DVI HDMI VGA Decoder is a professional audio & video decoding device. It’s for decoding SRT RTMP RTSP RTP UDP HTTP HLS FLV network video&audio stream to SDI/HDMI/VGA/DVI (with stereo audio) local display output.
Specifications
Video
Video Decoding Compression
H.264
Video input interface
Ethernet Port(RJ45)
Video bitrate Range
128Kbps ~ 40 Mbps
Video Output Interface
1*SD/HD/3G SDI，1*DVI-I (compatible with HDMI/DVI and VGA)
SDI Output Resolution
1080p60/59.94/50, 1080p30/29.97/25/24, 1080i59.94/60/50, 720p60/50, 480i59.94/60, 576i50
SDI Output Signal Types
SD-SDI(270M), HD-SDI(1.485G) and 3G-SDI(2.97G)
SDI Timing Jitter
SD SDI: ≤ 0.15UI, HD SDI: ≤ 0.8UI, 3G SDI: ≤ 1.7 UI
SDI Alignment Jitter
SD SDI: ≤ 0.15UI (1KHz), HD SDI: ≤ 0.2UI (10KHz), 3G SDI: ≤ 0.25UI (10KHz)
SDI Transmitting Distance
Belden 1694A cable standard: SD SDI ≥ 350m; HD SDI ≥ 180m; 3D SDI ≥ 100m
HDMI/DVI Output Resolution
1080p60/50, 1080p24/25/30, 1080i60/50, 720p60/50, 480p/576p, 480i/576i, VESA
VGA Output Resolution
1080p, 720p, UXGA(1600×1200), SXGA(1280×1024), XGA(1024×768), SVGA(800×600), VGA(640×480) , VESA
Audio
Audio Decoding Compression
AAC-LC /G.711 (aLaw/uLaw)
Audio Input Interface
Ethernet Port(RJ45), 1*3.5mm
Audio Output Interface
SDI, HDMI, 1*3.5mm
Others
Network Protocol
SRT, HTTP, UDP, RTSP, RTMP, HLS, FLV, TS
RJ45
1000M network interface
Control Panel
Web
Dimension(W*L*H)
138mm*105mm*27mm
Net Weight
0.38kg
Operation Temperature
-20℃~60℃
Power
DC12V 1A
Consumption
<5W
SDI output formats including 1080p60/59.94/50, 1080p30/29.97/25/24, 1080i59.94/60/50, 720p60/50, 480i59.94/60, 576i50
Up to 4ch 1080p30 (H.264) video decoding simultaneously
Support SRT RTMP RTSP RTP UDP HTTP HLS FLV TS protocols
Enhanced SDI Cable Driver can promise SD-SDI transmitting distance longer or equal to 350 meters, while HD-SDI transmitting distance is longer or equal to 180 meters, 3G-SDI transmitting distance longer than 100 meters
