Fiche Technique FTDI Chipset Cross Wired USB Serial DB9 FT232R USB RS232 Null Modem Cable Pc Control TV Cable (Null Modem (Laptop with USB Communicating with Desktop PC (with DB9 COM Port) au Maroc
DCE Molded Null Series USB FTDI Adapter Cable for Upgrade from Old Desktop Version DB9 – DB9 Cross Null Modem Cable
This cable is mainly used in PC (host) – PC (host) communication, also called null modem cable
This cable can also be used to control smart computer TV.
TV (as today the TV is a computer)
The other application of USB RS232 DB9 female cable is for PC (host) – device (slave), most of this application is 2-RX, 3-TX, 5-GND…..
The preview is the same, only the pinout is different,
Please note that
win8 10 android linux mac cross wired usb series db9 ftdi ft232r usb rs232 null modem cable
This cable allows your laptop (with USB, without DB9) to communicate with your desktop PC (with DB9 COM port)
communicated to each other.
RS232 Serial USB to Zero Modem Adapter (Cross)
USB 2.0 RS232 to DB9 Female Cable
FT232RL+ZT213 Chip
USB 2.0 standard, full speed.
Baud throughput up to 921.6 KB.
Null modem pinout (laptop with USB communicating with desktop PC (with DB9 COM port):
2-TXD (yellow), 3-RXD (orange), 5-GND (GND), 7-CTS (green), 8-RTS (brown), 1/4/6/9-NC
5C x 26AWG, Copper, 6ft, Black
Compatible with Android, Windows 10, 8, Win 7, XP, 2000, Linix, Mac OS.
Supports EEPROM, Vendor ID re-write support, Mprog3.5 support
Support FTDI VCP driver and D2XX driver.
Neutral packaging: zip poly bag
Length: 1.8m USB RS232 DB9 Cable
Chipset: FT232RL+ZT213 This is not a common cable, not a TTL cable. This is RS232 signal cable only.
Compatible with Android, Win 8, Win 7, Win 10, Linix, Mac OS, Internal Android EEPROM 1024 bytes
Driver Download: www.ftdichip.com, any questions, please contact us freely
