Simu Hz02 Micro Receiver for Roller Shutters, Suitable for Simu Hz Radio System and Somfy RTS Radio System (Motor Control) 230V/650WAvis, Fiche Technique et Prix au Maroc

Technical data:

• Product Category: Class III
• Rated voltage / motor voltage: 230 V AC, 50 Hz.
• Operating temperature: -40°C to +55°C.
• Protection class: IP20 (after installation).
• Radio frequency: 433.42 MHz rolling code.
• Transmitter supported: full range of SIMU-Hz transmitters (maximum 12 transmitters per receiver).

For roller blinds.

• Supported motors: all cable operated roller shutter motors.
• – Maximum switching current: 3 A / 240 V.
• Supported Switch: Switch/Button (no potential)

Version for light.

• 500W control output: for halogen lamps.
• 60W control output: for energy-saving / LED bulbs.
• Supported Switch: Switch/Button (no potential)

Product Description This convenient wireless receiver allows you to control a wired controlled motor by a wireless simu-Hz / Somfy RTS while retaining the original switch. Ultra-compact with only 41 x 45 x 19 mm and thanks to the quick release clamps, it takes only a few moments to install. Transform a “normal” roller shutter motor or integrate your existing SIMU/Somfy radio system with the lighting control. Play it safe with rolling code to avoid other people controlling your devices. Box contents: 1 x micro receiver and printed instructions.
Radio receiver compatible with Simu Hz02 and Somfy RTS radio system.
230 V / 50 Hz / -20 °C to + 55 °C / IP20 / 433.42 MHz / maximum switching capacity of 3.4 A.
Connection cable for external switch or push button – 2 intermediate positions or programmable comfort positions.
Minimum installation dimensions (41 x 45 x 19 mm) and quick terminals for minimal installation time.
For all shutter and blind motors with mechanical or end-of-stroke switches.
